TCIM-CNC-45T1
Add to inquiry box
Production information
MACHINE OVERVIEW
Offers greater punching and stamping capacity and improved machine stability compared with the 38T, with the capability to form larger products. A wire feed box can also be added to accommodate different feed length requirements.
SERIES CAPABILITY
Except for the 29T2, all other models support both punching and stamping operations, with different capacity levels to suit varying product sizes and forming requirements.
TECHNICAL SPECIFICATIONS
Wire Diameter1.5–5.0mm
Axes1
Press Capacity25ton
Max. Production Rate150pcs/min
| Wire Diameter | 1.5–5.0 mm |
| Wire Thickness | 0.3–2.0 mm |
| Wire Width | 40 mm |
| Wire Hardness (Carbon) | 80C |
| Axes | 1 |
| Max. Production Rate | 150 pcs/min |
| Max. Feed Length | 250 mm |
| Feed Method | Gripper Feed |
| Press Capacity | 25 ton |
| Slide Capacity | 6.5 ton |
| Press Stroke | 14 mm |
| Slide Stroke | Single Cam: 70 mm Double Cam: 65 mm |
| Slide Accessory | 6 |
| Machine Dimensions | 2,910 × 1,290 × 2,260 mm |
| Machine Weight | 2,660 kg |
* Specifications are subject to change without notice.
